Facilities Description



Chemistry Building



The Chemistry Department houses in the basement of the chemistry building a recently purchased  Bruker Ascend™ 700 MHz spectrometer, equipped with a variable temperature accessory, a digital temperature control unit and Z-gradient electronics.

Two probes are available for this instrument:

A room temperature   Inverse Triple Resonance (TXI) 5 mm Probe  for   1H observation and   13C and   15N decoupling, equipped with automatic tuning and matching module, and Z-gradient.

A Quadruple Resonance (QCI)  13C-enhanced 5 mm CryoProbe  for   1H observation with   13C,   15N and   31P decoupling, equipped with automatic tuning and matching module, and Z-gradient.

Bruker Ascend 700 MHz


Bruker Avance III console

A 500 MHz spectrometer recently upgraded with a   Bruker Avance III Console equipped with a variable temperature accessory, a digital temperature control unit and Z-gradient electronics.

Probes available for this instrument are:

A room temperature   Inverse Triple Resonance Broadband (TBI) 5 mm Probe for   1H observation and   13C and BB decoupling (tunable from   15N to   31P) equipped with Z-gradient.

A room temperature   SmartProbe™ (5 mm)  for X-nucleus observation tunable from   15N to   31P as well as   19F with   1H decoupling and observation, equipped with automatic tuning and matching module and Z-gradient.

A   CryoProbe Prodigy™ (5 mm) for X-nucleus observation tunable from   15N to   31P with   1H or   19F decoupling and observation, equipped with and automatic tuning and matching and Z-gradient.



A 400 MHz spectrometer recently upgraded with a   Bruker Nanobay Console equipped with a variable temperature accessory, a digital temperature control unit and Z-gradient electronics. This instrument has a   BBFO PLUS 5 mm probe   optimal for X-nucleus observation tunable from   15N to   31P as well as   19F with   1H decoupling and observation, equipped with Z-gradient and automatic tuning and matching.


A new   Bruker 300 MHz Ultra-Shield Fourier  spectrometer equipped with   1H and   13C amplifiers, variable temperature Control and Z-gradient electronics. A Room Temperature Fourier Dual 5 mm Probe for   13C-nucleus observation with   1H decoupling and observation and Z-gradient is currently installed on this instrument. Additionally, an older 300 MHz spectrometer operating with a   Varian Gemini 2300 gradient console  operating with a probe configured for observation of   1H,   13C,   19F, and   31P nuclei, completes the list of NMR spectrometers at the Chemistry Department. These two instruments are dedicated to teaching purposes and the simplest routine needs of organic synthesis laboratories of the Chemistry Department.

Brukner Nanobay

 CMM Building


Bruker Ascend 850

Located on the ground floor of the CMM, the NMR facility is equipped with a new  Bruker Ascend™ 850 MHz spectrometer with Z-gradient electronics and full temperature control capability for liquids and solids.

Probes currently available for this instrument are:

An  Inverse Triple Resonance (TXI) 5 mm probe for 1H observation and 13C and 31P decoupling with automatic tuning and matching and Z-gradient coil.

Triple Resonance (TCI) 13C-enhanced 5 mm CryoProbe for 1H observation and 13C with 15N decoupling that also provides exceptional 13C observe sensibility. The cryoprobe has automatic tuning and matching and a Z-gradient coil for gradients up to 100G/cm.

A  2.5 mm CP-MAS Probe with X channel tunable from 15N – 31P and high power 1H decoupling. MAS rates up to 35 kHz can be achieved.

A  3.2 mm CP-MAS Probe with fixed 13C and 15N observe channels, and high power 1H decoupling. MAS rates up to 24 kHz can be achieved.

A  4 mm CP-MAS Probe with X channel tunable from 15N – 109Ag and high power 1H decoupling. MAS rates up to 15 kHz can be achieved.





Bruker Avance 700 MHz spectrometer equipped with XYZ-gradient electronics and full temperature control capability for liquids and solids.

Probes available for this instrument are:

Triple Resonance (TCI) 5 mm Probe for 1H observation with 13C and 15N decoupling and XYZ-gradient coils.

An  Inverse Broadband 5 mm Probe for 1H observation with 109Ag – 31P decoupling and a Z-gradient coil.

5 mm Broadband Probe for X observation from 109Ag – 31P with 1H decoupling and a Z-gradient coil.

4 mm HR-MAS Probe with 1H, 13C, 15N and 2H channels, equipped with a gradient coil.

2.5 mm CP-MAS Probe with X observation from 13C - 31P and high power 1H decoupling. MAS rates up to 35 kHz can be achieved.



  Bruker Avance 700 MHz


Bruker Avance

Bruker Avance 600 MHz wide bore spectrometer equipped with kW amplifiers on all three channels, dedicated to advanced solid state experiments.

Probes available for this system are:

  • 2.5 mm CP-MAS H-F/X Probe for 19F-1H observation on the high frequency channel, 15N – 13C observation on the low frequency channel, high power 1H or 19F decoupling and spinning speeds up to 35 kHz.

4 mm CP-MAS H-F/X Probe for 19F - 1H observation on the high frequency channel, 15N – 13C observation on the low frequency channel, and simultaneous high power 1H and 19F decoupling. MAS rates up to 15 kHz can be achieved.

4 mm CP-MAS HX Probe for observation of 15N - 13C on the X channel and high power 1H decoupling. Spinning speeds up to 15 kHz can be achieved.

4 mm CP-MAS H/X/Y Probe for 13C/31P, 13C/17O, 13C/15N REDOR experiments with spinning speeds up to 15 kHz.

Static Triple Resonance BioPE Probe tunable to 1H, 13C and either 15N or 31P for PISEMA experiments.



 A  4 mm CP-MAS H-F/X Probe for 19F - 1H observation on the high frequency channel, 15N – 13C observation on the low frequency channel, and simultaneous high power 1H and 19F decoupling. MAS rates up to 15 kHz can be achieved.A Bruker Avance 500 MHz wide bore spectrometer equipped with kW amplifiers on all three channels, dedicated to advanced solid-state experiments.

Probes available for this system are:

  • 4 mm CP-MAS HX Probe for observation of 15N – 31P on the X channel and high power 1H decoupling. MAS rates up to 15 kHz can be achieved.

A  3.2 mm CP-MAS H/X/Y Probe with fixed 13C, 15N and 1H channels for REDOR experiments. MAS rates up to 24 kHz can be achieved.



  Bruker Avance
